Beava HTTP API

Status: Authoritative for v0. Documents the post-13.4 target route table — verb-style POST + JSON body for all 6 data-plane operations. Last reviewed: 2026-05-03 (Phase 13.0).

# Overview

Beava ships HTTP/1.1 + JSON as its primary data-plane transport so that any HTTP-speaking client — curl, browser fetch, a Lua-scripted load balancer, a WAF rewrite rule — can drive the server with no SDK. JSON is the only wire content-type on HTTP in v0; MessagePack is reserved for the framed-TCP fast-path only.

All 6 v0 data-plane operations are exposed as verb-style POST routes with a JSON request body. There is no GET-with-query-string path for /get or any other lookup; lookup arguments live in the request body. This convention matches Polars, DuckDB, and other contemporary devex-first analytic tools where the noun (/get, /push) names what is happening and the body carries the structured arguments. It also keeps the HTTP route table identical to the TCP opcode table — one transport reads as a literal translation of the other.

The full route table is:

The admin sidecar is a separate axum server on a separate port (cfg.admin_addr) per the Phase 12.6 mio-only invariant. It exposes 4 GET endpoints — /health, /ready, /metrics, /registry — and is the only place where tokio + axum touch the runtime. The data-plane port itself is hand-rolled mio + non-blocking I/O. See Admin sidecar endpoints below.

This doc is the HTTP transport spec; the body shapes (request and response schemas, error envelope, opcode-level semantics) live in docs/wire-spec.md. Every route listed here is a verb-form of an opcode in the wire spec, and each route description below cross-links to the matching opcode section.

# A note on the post-13.4 target state

The current code (post-12.7) uses event-name-suffixed routes for push: POST /push/{event_name}. This is a Phase 12.6 carry-over. Phase 13.4 (engine prep) renames the routes mechanically to the verb-style form documented in this doc — POST /push with event_name in the body. Phase 13.0 (this phase) declares the target state so that downstream SDK ports (Phase 13.5 Python, Phase 13.6 TS + Go) can author against a stable contract while the engine rename ships in parallel. After Phase 13.4 lands, this doc and the engine match exactly. See the Note on event-name routing section at the bottom for the migration rationale.

# Authentication and headers

Beava v0 ships unauthenticated. The OSS launch is intentionally an "unauthenticated single-process server" — operators front it with whatever auth proxy they use elsewhere (an internal LB, a Kong / Envoy / nginx in front, a service mesh, etc.). v0.1+ may grow opinions on auth; v0 has none.

There are no CORS headers in v0. The data-plane is a single-origin server inside a private network; cross-origin browser fetch is v0.1+ territory. If your client does need CORS, terminate it at your reverse proxy.

# Data-plane endpoints

The 6 sections below document each verb-style route. Bodies, schemas, and worked examples live in docs/wire-spec.md; this doc covers the HTTP-level surface (route + status codes + curl invocation).

# POST /register

Request body: see the wire-spec OP_REGISTER request schema. The full JSON Schema lives at examples/wire/schemas/register.request.schema.json.

The body declares one or more descriptors, each disambiguated by a kind discriminator (event | table | derivation). Per ADR-001, kind: "table" is the aggregation-output form — there is no app.upsert / app.delete / app.retract path for these tables in v0; they are populated only by upstream aggregation derivations. Per ADR-002, aggregation op names use the new Polars conventions (mean, var, std, n_unique, quantile).

Top-level flags:

• force=true — accept destructive schema changes (e.g. type change on a field). Default is false; destructive changes are rejected with registration_conflict.
• dry_run=true — run the validator and compute the diff without applying. Response carries added / removed / changed arrays; registry_version is unchanged.

Response body (success): see the wire-spec OP_REGISTER response schema. The full JSON Schema lives at examples/wire/schemas/register.response.schema.json.

The success response carries {status, registry_version, added, removed?, changed?, diff?}. registry_version is monotonic; clients use it as a cache key for schema-dependent state.

HTTP status codes:

Curl example:

curl -X POST http://localhost:8080/register \
  -H 'Content-Type: application/json' \
  -d @examples/wire/register-fraud-team.request.json

Errors specific to this endpoint:

See docs/error-codes.md for the alphabetical structured-code list with full HTTP status mapping (Plan 13.0-12 — forward reference).

# POST /push

Request body: see the wire-spec OP_PUSH request schema. The full JSON Schema lives at examples/wire/schemas/push.request.schema.json.

Path-style (recommended in v0): the engine accepts POST /push/{event_name} with body {"user_id": "alice", ...} — the body is the bare fields dict (the event name lives in the URL path). The fields object MUST match the registered event source's declared schema (same field names, compatible types). Type coercion on the JSON boundary is allowed in v0 — string "42" for an i64 field is accepted (the JSON-to-Rust coercer handles common mismatches). Strict-mode rejection is v0.1+.

Verb-style (also accepted): POST /push with body {"event": "", "data": {...}}. Both shapes are equivalent. SDKs prefer the verb-style form internally because it composes with batch dispatch on the TCP transport (OP_PUSH opcode + JSON body); curl users tend to find the path-style URL clearer.

Note: Earlier draft docs and the Phase-13.0 specs referred to a verb-style body of {event_name, fields}. The shipped engine accepts {event, data} instead; the older shape will return HTTP 400 missing_event_name_in_body.

Response body (success): see the wire-spec OP_PUSH response schema. The full JSON Schema lives at examples/wire/schemas/push.response.schema.json.

The success response carries {ack_lsn, registry_version}. ack_lsn is the server-assigned monotonic Log Sequence Number. v0 push is acks=1 per Phase 6.1 (SyncMode::Periodic) — the response returns after the WAL append returns success, before the periodic fsync flushes to disk. This is the intentional latency / durability tradeoff for v0; acks=all is reserved for v0.1+ via the wire-level opcode OP_PUSH_SYNC = 0x0011.

HTTP status codes:

Curl example (path-style — simplest):

curl -X POST http://localhost:8080/push/Txn \
  -H 'Content-Type: application/json' \
  -d @examples/wire/push-success.request.json

Or with the verb-style body that the SDKs send internally:

curl -X POST http://localhost:8080/push \
  -H 'Content-Type: application/json' \
  -d '{"event": "Txn", "data": {"user_id": "u123", "amount": 42.5}}'

The wire-level fixture examples/wire/push-success.request.json carries only the bare fields dict, which is the path-style body. To replay it via verb-style, wrap it as {"event": "Txn", "data": } with jq.

Errors specific to this endpoint:

# POST /get

Request body: see the wire-spec OP_GET request schema. The full JSON Schema lives at examples/wire/schemas/get.request.schema.json.

The body shape is {table, key, features?}:

• table is the table name registered with OP_REGISTER.
• key is either a string (single-key tables) or a homogeneous JSON array of [string|number|boolean] elements for composite-key tables. Composite-key arrays follow the same order as the table's declared key field.
• features is optional — limits the response to a subset of the table's features. Omitting it returns all features for the row.

Response body (success): see the wire-spec OP_GET response schema. The full JSON Schema lives at examples/wire/schemas/get.response.schema.json.

The success response is the row-shape itself — a flat JSON object with feature names as keys. Cold-start (no events ever pushed for this key) returns {} with HTTP 200 — empty result is success, not error. This matches the Redis-shaped contract: a cold key is just a key with no data, not a 404-class condition.

HTTP status codes:

Curl example:

curl -X POST http://localhost:8080/get \
  -H 'Content-Type: application/json' \
  -d @examples/wire/get-found.request.json

Errors specific to this endpoint:

# POST /batch_get

Request body: see the wire-spec OP_BATCH_GET request schema. The full JSON Schema lives at examples/wire/schemas/batch_get.request.schema.json.

The body shape is {requests: [{table, key, features?}, ...]}. The batch is heterogeneous — different table values can appear within the same batch. Each entry has the same per-entry semantics as a single OP_GET.

The server enforces a maximum entries-per-batch cap. The current cap is 10000 (per crates/beava-runtime-core/src/wire_request.rs SRV-API-08); a batch that exceeds the cap is rejected with batch_too_large (HTTP 400). Operators can lower this via configuration; raising it requires a server recompile in v0.

Response body (success): see the wire-spec OP_BATCH_GET response schema. The full JSON Schema lives at examples/wire/schemas/batch_get.response.schema.json.

The success response is {results: [row-shape, ...]}. The order of results matches the order of requests. Per-entry cold-start is {}; per-entry rows are flat dicts of feature → value. There is no partial success in v0 — if any single request entry has an error (unknown_table, key_shape_mismatch, etc.), the entire frame returns OP_ERROR_RESPONSE with the offending request indexed in the path field (e.g., requests[2].table). Clients re-issue with the bad request removed. Partial success is reserved for v0.1+.

HTTP status codes:

Curl example:

curl -X POST http://localhost:8080/batch_get \
  -H 'Content-Type: application/json' \
  -d @examples/wire/batch_get-heterogeneous.request.json

Errors specific to this endpoint:

# POST /reset

Request body: an empty JSON object {}. See the wire-spec OP_RESET request schema. The full JSON Schema lives at examples/wire/schemas/reset.request.schema.json.

Response body (success): {"status": "ok"} after WAL truncation completes. The call is synchronous — the next event push to the same connection observes the cleared state. See the wire-spec OP_RESET response schema. The full JSON Schema lives at examples/wire/schemas/reset.response.schema.json.

Destructive. OP_RESET wipes all in-memory state and truncates the WAL. It is intended for test fixtures (bv.test.fixture and the BeavaTestServer harness use it between tests). Production operators MUST NOT call /reset on an instance bound to live data. Operators concerned about misuse should boot without test mode (the v0 default) — the route then returns 403 Forbidden with reset_disabled_in_production.

HTTP status codes:

Curl example:

curl -X POST http://localhost:8080/reset \
  -H 'Content-Type: application/json' \
  -d @examples/wire/reset-request.json

Or, since the body is empty:

curl -X POST http://localhost:8080/reset \
  -H 'Content-Type: application/json' \
  -d '{}'

Errors specific to this endpoint:

# POST /ping

Request body: an empty JSON object {} (or absent — the parser tolerates empty body for /ping). See the wire-spec OP_PING request schema. The full JSON Schema lives at examples/wire/schemas/ping.request.schema.json.

Response body (success): {"server_version": "<semver>", "registry_version": <integer>}. See the wire-spec OP_PING response schema. The full JSON Schema lives at examples/wire/schemas/ping.response.schema.json.

server_version is the beava server's semantic version (e.g., "0.0.0" for the v0 launch). registry_version is a monotonic counter that increments on every successful OP_REGISTER; clients use it as a cache key when caching feature schemas.

HTTP status codes:

Curl example:

curl -X POST http://localhost:8080/ping \
  -H 'Content-Type: application/json' \
  -d @examples/wire/ping-request.json

Errors specific to this endpoint: none in the operational sense — /ping does not validate any input.

# Admin sidecar endpoints (separate port, GET-shaped)

The admin sidecar binds on cfg.admin_addr — a separate port from the data-plane HTTP listener. Per the Phase 12.6 mio-only Hot-Path Invariant, the data plane is the hand-rolled mio + non-blocking I/O loop and the admin sidecar is the only place tokio + axum run in the runtime. This separation is enforced by the architectural test crates/beava-server/tests/phase12_6_mio_only_dataplane.rs — adding a third caller of apply_event_to_aggregations or introducing axum::* symbols outside http_admin.rs fails CI.

The admin sidecar is GET-shaped (idempotent, cacheable, friendly to operator tooling):

# GET /health

Response: HTTP 200 with body {"status": "ok"} whenever the admin server is up. This is a cheap liveness probe — it does NOT confirm that the registry is loaded or that the data-plane has finished WAL recovery; for that, use /ready.

Suitable for Kubernetes / Nomad / systemd-style liveness probes.

# GET /ready

Response: HTTP 200 with body {"status": "ready"} only after recovery is complete (snapshot loaded + WAL replayed and the data-plane is dispatching events). HTTP 503 Service Unavailable while recovery is in progress.

Suitable for Kubernetes / Nomad / systemd-style readiness probes — gates the service from receiving traffic until the cold-start replay finishes.

Back-compat note: the data-plane port also exposes GET /ready and GET /health at cfg.bind_addr for back-compat with the ~20 test files that poll ts.base_url() for readiness. The canonical location is the admin sidecar; the data-plane mirroring is a Plan 12.6-01 carry-over and may be removed in v0.0.x.

# GET /metrics

Response: Prometheus exposition format (text/plain; version=0.0.4; charset=utf-8).

The metric families exposed in v0 are:

• beava_registry_version (gauge) — monotonic.
• beava_node_count (gauge) — number of registered aggregation nodes.
• beava_runtime_kind{runtime="mio"} 1 (gauge) — pins the data-plane runtime identity per project_phase18_no_dual_runtime.
• beava_entropy_categories_capped_total (counter) — entropy operator cap-hit total.
• beava_cold_entity_evictions_total (counter) — cold-TTL entity evictions (Plan 12.8-03).
• beava_lifetime_op_cap_hit_total (counter) — lifetime aggregation cap-hit total.
• beava_entity_count_resident (gauge) — current resident entity count.
• beava_bucket_reclaim_total (counter) — windowed-op trailing-bucket reclaims (AGG-CORE-09 64-bucket cap firings).
• beava_bytes_per_entity_p99 (gauge) — static v0 estimate of per-entity memory footprint (~7000 bytes per Phase 12.9 verification).

See docs/architecture/observability.md (Plan 13.0-13 — forward reference) for the full metric-family catalogue, label discipline, scrape interval recommendations, and Phase 12.8 memory-governance counter semantics.

# GET /registry

Response: HTTP 200 with body {"version": <integer>, "node_count": <integer>} (plus extended fields in v0.0.x; the v0 ship surface is the version + node count). An optional ?version=N query parameter requests a historical snapshot for debugging — implementation lands in v0.0.x; the v0 ship surface is the current snapshot only.

Back-compat note: the data-plane port also exposes GET /registry for back-compat with phase4 / phase5 / phase11.5 tests that GET /registry to assert schema propagation. As with /ready + /health, the canonical location is the admin sidecar.

# Error envelope format

Every 4xx and 5xx response carries the standard error envelope per examples/wire/schemas/error.schema.json:

{
  "code": "<structured-code-string>",
  "path": "<JSON-or-DAG-path>",
  "message": "<human-readable-string>"
}

• code is a structured machine-readable identifier. Stable across releases. The canonical alphabetised list with full HTTP status mapping lives at docs/error-codes.md (Plan 13.0-12 — forward reference).
• path is an optional JSON path or DAG path locating the offending element. Examples: descriptors[1].schema.amount (during register validation), fields.amount (during push), requests[2].table (during batch_get).
• message is a human-readable explanation. Forward-looking framing per Phase 12.7 D-02 — messages say "X is not supported in v0", not "X has been removed" or "X was deprecated". The framing avoids implying a previous-version reference for users who never saw older revisions of the product.

The error envelope is identical on both transports — TCP wraps it in a frame with op = 0xFFFF (OP_ERROR_RESPONSE) and content_type = 0x01; HTTP returns it as the response body with the appropriate status code.

Worked example: examples/wire/register-conflict.error.json.

# Connection lifecycle

• Single TCP connection per App instance. Each SDK creates one HTTP/1.1 connection (with keepalive) per App. Multi-connection pools inside one App are reserved for v0.1+. Concurrent calls on the same App from multiple threads serialise on the connection.
• Auto-reconnect on drop. If the server closes the connection (e.g., during a graceful restart), the SDK's transport layer transparently reconnects on the next call. v0 keeps this behaviour conservative — there is no exponential backoff configuration; the SDK retries at most once per call, and the call surfaces the error if both attempts fail.
• Keepalive cadence. Server respects standard TCP keepalive; v0 does not pin a value. Reverse-proxies in front of beava (nginx, Envoy) typically enforce their own idle-timeout; aim to keep the SDK's idle-timeout below the proxy's.
• Idempotency. Per Phase 6.1, push idempotency is opt-in via the dedupe_key + dedupe_window fields registered on the event source. Duplicate pushes within the window return the prior ack_lsn plus idempotent_replay: true. See docs/wire-spec.md for the full dedupe semantics.

# Note on event-name routing

A short clarification on the route-rename:

The verb-style body shape is {"event": "", "data": {...}} (both keys required); the path-style body is the bare fields dict. Other routes (/register, /get, /batch_get, /reset, /ping) are verb-style in the current code.

The rename rationale aligns with project_v2_devex_first and the broader Polars / DuckDB voice (feedback_beava_website_voice):

• Verb-style is more REST-ful in the strict sense — the URL names the operation; the body carries the structured arguments. Lookups, registers, pushes, and resets all read identically.
• One-to-one match with the wire opcode table. TCP carries OP_PUSH with the event name in the body; HTTP carries POST /push with the event name in the body. The two transports become a literal translation, which makes SDK porting trivial in 13.6 (the TCP framer is the only logic per opcode; the HTTP transformation is frame.body → request.body).
• No path-segment escaping. Event names with /, spaces, or non-ASCII characters require URL-encoding in the path-arg style; the body-arg style treats them as plain JSON strings.

SDKs (Plan 13.5 Python, Plan 13.6 TS + Go) ship against the post-13.4 form from day one. The Python SDK does NOT carry a deprecation-alias path for the old route — pre-13.0 dev users (small group, no production deploys yet) move to the new form directly when they upgrade past v0.0.0. The deprecation window for the route rename is "the gap between current code and v0.0.0 release"; once v0.0.0 ships, only the new form is supported.

# Plan-level traceability

This document is authored by Plan 13.0-03 (Wave 1). It declares the post-13.4 target HTTP route table and is read by:

• Plan 13.0-04 (docs/sdk-api/{python,typescript,go}.md) — per-language SDK API specs target the verb-style routes documented here.
• Plan 13.0-12 (docs/error-codes.md) — alphabetised structured-code list referenced by the code field in this doc's error tables.
• Plan 13.0-13 (docs/architecture/observability.md) — admin sidecar metric catalogue referenced by GET /metrics above.
• Phase 13.4 — engine implementation that mechanically renames push routes to the verb-style form documented here.
• Phase 13.5 / 13.6 — Python / TS / Go SDKs that send requests against these routes.

For the full Phase 13.0 plan tree, see .planning/phases/13.0-design-contract-spec-docs/13.0-PLAN.md.
